neat-dnfs

A NeuroEvolutionary Framework for Evolving Dynamic Neural Field Architectures

---

neat-dnfs is a C++ framework that extends NeuroEvolution of Augmenting Topologies (NEAT) to the automated synthesis of Dynamic Neural Field (DNF) architectures. It enables the joint evolution of continuous-time neural dynamics, kernel-based interactions, and architectural topology, supporting the discovery of compact and interpretable Dynamic Field Theory (DFT) models without manual tuning.

---

Overview

Dynamic Neural Fields (DNFs) provide a biologically grounded and mathematically principled framework for modelling neural population dynamics underlying perception, working memory, selection, and decision-making. Despite their expressive power, DNF architectures are traditionally hand-designed and manually parameterised, a process that is time-consuming, difficult to generalise, and highly dependent on expert knowledge.

neat-dnfs addresses this limitation by integrating DNFs with neuroevolution. By extending NEAT to operate directly on neural fields and spatial interaction kernels—rather than discrete neurons and scalar weights—the framework enables the autonomous discovery of DNF architectures that exhibit desired dynamical behaviours.

The system evolves both:

• Intrinsic field dynamics (e.g., time constants, resting levels, kernel profiles)
• Inter-field structure (number of fields and their spatial couplings)

Evolution proceeds from minimal architectures and introduces complexity only when required by task constraints, in line with the minimal cognitive construction principle.

---

Key Features

• Evolution of Dynamic Neural Field Architectures Simultaneous evolution of neural field parameters and architectural topology.

• Continuous-Time, Kernel-Based Neuroevolution Genomes encode spatial interaction kernels and field dynamics instead of discrete synaptic weights.

• Incremental Structural Complexification New fields and interactions emerge gradually through NEAT-style structural mutations.

• Interpretability by Design Evolved solutions consist of explicit neural fields with identifiable functional roles.

• Task-General Framework Applicable to a hierarchy of DFT-inspired tasks, from basic instabilities to compositional cognitive paradigms.

• Comprehensive Evolutionary Analysis Built-in logging, statistics, and visualisation of species, genomes, and architectural growth.

---

Architecture

Core Components

Component	Description
Genome	Encodes a DNF-based architecture as field genes and interaction genes.
Population	Manages evolution, evaluation, selection, and reproduction.
Species	Groups similar architectures to protect structural innovation.
Solution	Defines task-specific fitness evaluation based on field dynamics.
Field Genes	Represent individual neural fields (input, hidden, output) and their intrinsic dynamics.
Interaction Genes	Represent spatially structured kernel-based couplings between fields.

Genotype-to-phenotype mapping in neat-dnfs. Field genes encode intrinsic neural field dynamics, while interaction genes specify kernel-defined couplings. Together, they map directly to a continuous-time DNF architecture.

---

Evolutionary Process

1. Initialization – Start from ultra-minimal architectures (input and output fields only).
2. Simulation – Evaluate continuous-time DNF dynamics under task-specific stimuli.
3. Fitness Evaluation – Assess qualitative dynamical properties (e.g., peak formation, stability, selection).
4. Speciation – Protect novel architectural innovations using compatibility distance.
5. Selection & Reproduction – Apply NEAT-style crossover and fitness sharing.
6. Mutation – Refine parameters or introduce new fields and interactions.

---

Implemented Tasks

The framework includes a hierarchy of benchmark tasks designed to probe increasingly complex DFT mechanisms:

Core Dynamic Mechanisms

• Detection Instability – Transient input-driven activation and decay
• Memory Instability – Self-sustained activation without input
• Selection Instability – Winner-take-all competition

Compositional Tasks Requiring Structural Innovation

• Delayed Match-to-Sample (DMTS) – Internal memory biasing later selection
• Inhibition of Return (IOR) – Delayed inhibitory bias against previously selected locations

Additional simple logical tasks (e.g., AND, XOR) are included for validation and demonstration.

---

Building

Prerequisites

• CMake 3.31.6+
• C++20 compiler
• VCPKG package manager

Dependencies (via VCPKG):

• imgui, implot, imgui-node-editor, nlohmann-json

Additional dependencies:

• imgui-platform-kit
• dynamic-neural-field-composer

Build Instructions

export VCPKG_ROOT=/path/to/vcpkg
mkdir build && cd build
cmake ..
cmake --build . --config Release

---

Usage

Basic Example

#include "neat/population.h"
#include "solutions/xor.h"

XOR solution{ SolutionTopology{{
    { {FieldGeneType::INPUT, {50, 1.0}},
      {FieldGeneType::INPUT, {50, 1.0}},
      {FieldGeneType::OUTPUT, {50, 1.0}} }
}}};

PopulationParameters parameters{100, 150, 0.95};
Population population{parameters, std::make_unique<XOR>(solution)};
population.initialize();
population.evolve();

Custom Tasks

To define a new task:

1. Inherit from the Solution base class
2. Specify the initial minimal topology
3. Implement evaluate() using field-dynamics-based fitness criteria

void evaluate() override
{
    // Define fitness in terms of DNF dynamics:
    // peak existence, position, amplitude, width, or decay to baseline
    parameters.fitness = computedFitness;
}

---

Statistics and Analysis

The framework automatically records:

• Fitness evolution
• Species diversity and lineage
• Architectural complexity (fields and interactions)
• Mutation and structural growth statistics

All data are stored in the data/ directory.

Analysis Tools (analysis/)

• Per-generation fitness and diversity
• Genome and mutation statistics
• Architectural complexity tracking

Run the launch-visualizer.bat to open a Streamlit app, and then select the experiment directory.

---

Project Structure

neat-dnfs/
├── include/
│   ├── neat/          # Core NEAT-DNF implementation
│   ├── solutions/     # Task definitions
│   ├── tools/         # Logging and utilities
│   └── constants.h    # Hyperparameter definition
├── src/
├── examples/
├── tests/
├── data/              # Evolution outputs
├── analysis/          # Post-hoc analysis tools
└── CMakeLists.txt

---

Video explanation

---

Documentation

For a full exploration of the repository, refer to the Wiki.

---

Main inspiration for this work

• Amari, Shun-ichi (1977) - "Dynamics of pattern formation in lateral-inhibition type neural fields"
• Schöner, Gregor and Spencer, John and Research Group, Dft (2015) - "Dynamic Thinking: A Primer on Dynamic Field Theory"
• Nolfi, Stefano and Floreano, Dario (2000) - "Evolutionary robotics: the biology, intelligence, and technology of self-organizing machines"
• Floreano, Dario (2023) - "Bio-Inspired Artificial Intelligence: Theories, Methods, and Technologies"
• Erlhagen, Wolfram and Bicho, Estela (2006) - "The dynamic neural field approach to cognitive robotics"
• Krichmar, Jeffrey L. (2018) - "Neurorobotics — A Thriving Community and a Promising Pathway Toward Intelligent Cognitive Robots"
• Stanley, Kenneth O. and Miikkulainen, Risto (2002) - "Evolving Neural Networks through Augmenting Topologies"
• Erlhagen, Wolfram and Bicho, Estela (2014) - "A Dynamic Neural Field Approach to Natural and Efficient Human-Robot Collaboration"
• Pfeifer, Rolf and Bongard, Josh (2006) - "How the Body Shapes the Way We Think: A New View of Intelligence"
• Coombes, Stephen and Beim Graben, Peter and Potthast, Roland and Wright, James (2014) - "Neural fields: theory and applications"
